carbon steel sockolet

Sockolet is similar to a Weldolet, with the difference that the branch pipe is connected to the run pipe, via the fitting, with a socket weld connection as per ASME B16. 11. Likewise Weldolets, Sockolets are used to make a 90-degree pipe branch. Sockolets may be “size on size” or “reducing”.

Product Description

The sockolet (socket weld outlet) is mainly used for the reinforcing pipe fittings connected by the branch pipe, instead of using the branch pipe type such as the reducer, the reinforcing plate and the reinforcing pipe section, it is safe and reliable, reduces the cost, simple construction, improves the medium flow channel, and series. The advantages of standardization, design and selection are convenient, especially in high-pressure, high-temperature, large-diameter, thick-walled pipelines, which replaces the traditional branch pipe connection method. The main body of the branch pipe is made of high-quality forgings, and the materials are the same as the pipe materials, such as carbon steel, alloy steel and stainless steel. Commonly used manufacturing standards for socket welding pipe stands are ASME B16.11, GB/T 7306, 12716, 14383, MSS SP-79, 83, 95, 97, JIS B0203, B2316.

Material:
A. Stainless steel: F304, F316L, F310S, F317L, F321, F347
B. Carbon steel: A105, A106, A53, A234 WPB
C. Alloy steel: LF2, F5, F9, F11, F22
D. Duplex steel: F44, F51, F53, F55, F60
E. Special steel: 904L, UNS N04400, UNS N08810, UNS N08020, UNS N08825, UNS N06625, UNS N06600
Pressure:
3000# – for use with Sch. 80 pipe.
6000# – for use with Sch. 160 pipe.
