Ozone Detector For Air

Ozone Detector For Air

Product Description

This Ozone detectors is a kind of portable ozone detector that are designed to measure the levels of ozone present in the air. It has different measure ranges which typically range from 0-10ppm, 0-20ppm, 0-50ppm, to 0-100ppm. These ranges allow for accurate measurements of ozone levels in various settings such as industrial plants, laboratories, and public areas.

Ozone detectors are equipped with sensors that can detect the presence of ozone gas in the air. When the ozone level reaches a certain threshold, the detector will trigger an alarm to alert people in the area of potential danger. The alarm can be in the form of a loud audible signal, flashing lights, or even a text message alert.

These detectors are commonly used in environments where ozone exposure can be harmful to human health or cause damage to equipment. For example, they are commonly used in laboratories where ozone may be generated during chemical reactions, or in industrial plants where ozone is produced as a byproduct of certain manufacturing processes.

Specification of portable ozone detector

Gas Detected

Ozone O3

Detection principle

Electrochemical principles

Sampling Method

Pump- suction, flow up 1L/min, pump suction size ten stalls adjustable

Data logger

100,000 sets of data can be stored, storage interval available set, minimum 5S, can be browse

Measure Range

0-10ppm, 0-20ppm, 0-50ppm, 0-100ppm

Resolution

0.01ppm

Precision

2% FS

Response Time

≤ 10S

Repeatability

≤ ± 1%

Zero shift

≤ ± 1% (F.S / Year)

Operating language

Support in English

Temperature

-40 ℃ ~ 70 ℃

Explosion-Proof

Exia Ⅱ CT4

Alarm mode

Sound, light, vibration

Dimensions

205*75*32mm

Recovery Time

≤ 10S

Linearity error

≤ ± 1%

Display

LCD

Gas unit

multiple gas unit

Humidity

0-95% RH

Degree of protection

IP66

Operating time

100 hours (off pump)

Weight(net)

300g



Function of Ozone Detector For Air

1. Monitoring of the environment, or the concentration of ozone O3 in a confined space and give an alarm

2. With self-check function, zero calibration function, so that gas monitoring more accurate and reliable

3. One key to restore the factory settings, can be removed from misuse problems

4. With temperature and pressure compensation, to achieve the perfect, different temperature and pressure environment, the gas concentration compensation

5. Two sound and light alarm, alarm point can be set

6. Large-capacity lithium polymer rechargeable battery

7. Pump suction sampling, adjustable suction pump

8. Shell with high-strength special engineering plastics, non-slip, waterproof, dustproof, explosion

9. Exquisite upscale aluminum suitcase
