Oushang solar is one of China's top photovoltaic module manufacturers with an annual production capacity of 500MW. Any product (including Customized Solar Panels) undergoes a number of technical tests to ensure that the product is flawless.
Product Description
Oushang solar is one of China's top photovoltaic module manufacturers with an annual production capacity of 500MW. Any product (including Customized Solar Panels) undergoes a number of technical tests to ensure that the product is flawless.
You can Customized Solar Panels products range from 5W-500W. And according to your specific application scenarios, you need to provide different voltages. Contacting us will be the first step in customization!
We can manufacture photovoltaic modules according to customer requirements.
Everything about the solar panel can be customized, battery, frame, color, backplane, cable, junction box, size, connector, power supply, etc.
1. Different sizes
2. Different textures
3. Different shapes
Solar tile
Roof slate
Building Integrated Photovoltaics (BIPV)
Any shape
Custom materials
The latest solar cell technology
To provide OEM Customized Solar Panels to customers around the world, our team is located in China, and reliable solar panels have been proven to operate in different climates and environments around the world. More than 20GW has been shipped to Africa, Europe, Central America, the Middle East, and Southeast Asia.
Customized Solar Panels are widely used all over the world for mobile systems, small home solar systems, garden solar systems and optical sensors, traffic counters, electronic fence chargers, security systems, utility meters, geophysical instruments, satellite/mobile charging, Oil and gas well flow meters, marine buoys, marine telemetry systems, marine seismic systems, traffic warning devices, global positioning systems, information kiosks, asset tracking, outdoor lighting systems, weather monitoring systems, fleets, grid connection, lighting, security, alarms, cameras , Telecommunications, pumping, boating, off-grid, agricultural applications, caravans.
1. Our factory has advanced automated production lines. Whether you are developing new products, modifying existing products, or looking for inventory solutions, Auchan Solar has the perfect solution.
2. We adopt strict production technology and quality control system to ensure the perfect quality of manufactured products. Our most advanced monolithic solar modules are stronger than any other solar modules on the market and far exceed the performance of typical laminate or glass solar modules.
3. The quality inspection follows the ISO9001 standard. No other factory can provide a 15-year warranty! Using Auchan's customized solar modules can ensure that your products are optimized for performance and are completely reliable.
4. Our company's solar module products have passed TUV, SGS, CE, SONCAP, CQC testing. Extending battery life can reduce product life cycle costs. The battery keeps running while charging, so no external charging equipment is required.
5. Our factory has passed Intertek inspection. Contact us for free advice!
Customized solar panels offer a unique and efficient way to harness the power of the sun. By tailoring your solar panel system to your specific needs, you can optimize energy production, reduce costs, and make a positive impact on the environment. Embrace the potential of customization and take a significant step towards a sustainable future with customized solar panels. Let the sun illuminate your path to a greener, cleaner, and more energy-efficient tomorrow.
Module Type |
OS-M36-50 |
|
Maximum Power (Pmax) |
50W |
|
Maximum Power Voltage (Vmp) |
18.0V |
|
Maximum Power Current (Imp) |
2.78A |
|
Open Circuit Voltage (Voc) |
21.8V |
|
Short Circuit Current(Isc) |
2.95A |
|
Number of Cells |
36(3*12) |
|
Dimensions (mm) |
670*540*30 |
Module Type |
OS-M36-80 |
|
Maximum Power (Pmax) |
80W |
|
Maximum Power Voltage (Vmp) |
18.0V |
|
Maximum Power Current (Imp) |
4.45A |
|
Open Circuit Voltage (Voc) |
21.8V |
|
Short Circuit Current (Isc) |
5.38A |
|
Number of Cells |
36 (4*9) |
|
Dimensions (mm) |
830*670*30 |
Module Type |
OS-P36-50 |
|
Maximum Power (Pmax) |
50W |
|
Maximum Power Voltage (Vmp) |
18V |
|
Maximum Power Current (Imp) |
2.78A |
|
Open Circuit Voltage (Voc) |
21.8V |
|
Short Circuit Current (Isc) |
2.95A |
|
Number of Cells |
36(3*12) |
|
Dimensions(mm) |
670*540*25 |
Module Type |
OS-P36-80 |
|
Maximum Power (Pmax) |
80W |
|
Maximum Power Voltage (Vmp) |
18V |
|
Maximum Power Current (Imp) |
4.45A |
|
Open Circuit Voltage (Voc) |
21.8V |
|
Short Circuit Current (Isc) |
5.38A |
|
Number of Cells |
36(4*9) |
|
Dimensions(mm) |
830*670*30 |
We welcome you to send your requirements of solar panels. We will try our best to meet all your products standard.
