Orthophoto

Product Description

Specifications

Description

Feiyan Technology specialises in high-resolution orthophoto map production including digital orthophotos and orthophoto mosaics from raw aerial survey photography and digital image capture. Orthophotos combined with a topographic mapping project give a precise reference backdrop tool that enhances the users understanding of any project area. Combined into orthophoto mosaics the imagery can cover large areas such as a catchment, river basin, highway or even local government area.

Features & Benefits of Orthophoto

Orthophoto is an aerial photograph that has been geometrically corrected or ortho-rectified so that the scale of the photograph is uniform and utilised in the same manner as a map. An orthophotography can be used to measure true distances of features within the photograph. Planimetric corrections have been applied to remove lens distortions and optics, camera angle, and differences in elevation through a process of measuring ground control points to connect the photo to the ground, in a drawing-pin like manner. An orthophoto is an accurate representation of the Earth' s surface. Orthophoto has the benefits of high detail, timely coverage combined with the benefits of a map including uniform scale and true geometry.

Specifications of Orthophoto

Resolution: 0.1m

Project area: 4,200km²

Duration: 90 days

Output: DOM(1:1000)

Application: The Third National Land Survey of Putian City

From: Putian City Land and Resources Bureau


Terms

FOB Price:
Minimum Order: 1
Port: /
Payment Terms: tt
